Action Camera SD Memory Card Africa Sd Memory Cards 256 Gb 128gb 64gb
Wholesale Action Camera SD Memory Card Africa Sd Memory Cards 256 Gb 128gb
What is the real capacity?
Flash memory vendors are using decimal arithmetic:1MB = 1000KB,1G = 1000MB
calculated, the operating system using binary arithmetic:1MB = 1024KB,1GB = 1024MB;
so there are some differences between display capacity and nominal capacity of flash memory product.
4GB = approximately 3.6GB-3.8GB
8GB = approximately 7.4GB-7.6GB
16GB=approximately 14GB-15GB
32GB=approximately 28GB-30GB
64GB=approximately 58GB-60GB
128GB=approximately 115GB-119GB
256GB=approximately 230GB-238GB
Product Name
Custom Logo 2GB/4GB/8GB/16GB/32GB/64GB/128GB/256GB/512GB TF Card
Material
Plastic
Size
15*11*1mm
Logo options
1-4 Color Print, Laser engraving
Capacity
4GB C10/8GB C10//16GB U3/32GB U3/64GB U3/128GB U3/256GB U3/512GB U3
Writing speed
10-40M/S
Reading speed
70-120M/S
OEMODM
Customers Could Customized Your Unique Products, as We Provide Full Service From PCBA Development,Semiconductor Storage R&D Solutions,Mold Casting,Professional Integrated Circuits Advanced Packaging and Testing ,Production Control to Shipment Arrange.
Certification
CE, FCC,ROHS,UKCA
Application
Camera / PSP / Tablet / Smartphone / Car DVR GPS /MP3 / MP4 / Laptop
Speed Class
V90 CLASS4 U3 V60 A1 Class2 V30 U1 CLASS10 optional
Ultra High Speed (UHS) Card
It provides up to 104MB/s* performance.
UHS cards are backward compatible on non-UHS hosts.
*Based on internal testing; performance may vary depending upon host device.
1 megabyte (MB)=1,000,000byte
Note:
Measurement based on VTE3100 & VTE4100 TestMetrix device, SW 3.2A software or up version.
The card must be reformatted between each script test.
Features:
Flash Type: MLC or 3D NAND Type
Chip: A grade original wafer solutions
Capacity: 4GB C10/8GB C10//16GB U3/32GB U3/64GB U3/128GB U3/256GB U3/512GB U3
Socket: Micro SD2.0 or Micro SD 3.0
Operating humidity: 5 to 90%
Operating Temperature: 0°C ~60°C Or customized standard
Speed Rate Range: Read: 70MB/S -95MB/S Write: 10MB/S-30MB/S
Speed Class: V90 CLASS4 U3 V60 A1 Class2 V30 U1 CLASS10 optional
Erase Cycles: 10 ,000 times
Bus Speed Mode:
Ø DS-Default Speed mode: 3.3V signaling, frequency up to 25MHz, up to 12.5MB/sec
Ø HS-High Speed mode: 3.3V signaling, frequency up to 50MHz, up to 25MB/sec
Ø SDR12-1.8V signaling, frequency up to 25MHz, up to 12.5MB/sec
Ø SDR25-1.8V signaling, frequency up to 50MHz, up to 25MB/sec
Ø SDR50-1.8V signaling, frequency up to 100MHz, up to 50MB/sec
Ø SDR104-1.8V signaling, frequency up to 208MHz, up to 104MB/sec
Ø DDR50 -1.8V signaling, frequency up to 50 MHz, up to 50MB/s.
Switch function command supports Bus Speed Mode, Command System, Drive
Strength, and future functions.
Content Protection Mechanism - Complies with highest security of SDMI standard.
Built-in write protection features (permanent and temporary)
Password protection (CMD42-LOCK_UNLOCK).
Sophisticated system for error recovery including a powerful ECC.
Global Wear Leveling.
Weight: SD Card Max. 2.5g / microSD Card Max. 1g
Dynamic Power Management Technology
– Quick standby, auto-suspend, and sleep operations.
– Sleep current: about 100uA
All-Round Data Storage Solutions
* IC Memory Packaging and Testing Services
* IC Memory OEM & ODM
* PCBA Development,R&D Solutions
* UDP Chip Factory Direct Price
FAQ:
1. Are you factory?
Yes, we are leading factory for 10 years.
Jingfeng is a specialized and special new high-tech enterprise focusing on innovative product solutions for semiconductor memory and advanced packaging and testing services for professional integrated circuits.
2. What do I need to create a custom UDP flash chip/TF Card/SSD?
All you need is a desire, our Account managers will take care of the rest.
3. What do I need to create a custom UDP flash chip/TF Card/SSD?
All you need is a desire, our Account managers will take care of the rest.
4. What kinds of logo we can put on the UDP flash chip/TF Card/SSD?
It depend on different model, generally they are silk printing ,laser logo,full printing, pad printing or epoxy logo.
5. How much does it cost to create custom UDP flash chip/TF Card/SSD?
With our revolutionized process, the cost is almost the same as printing your logo on standard flash drives.
6. Are they less expensive without logos?
When we create custom shaped products, the logo becomes part of the design. Therefore, the price is the same. However, there is a savings if you choose from our existing custom shaped products.
7. What are the color options?
This is custom product that is created for you from scratch. You can choose any color, material, size, or shape.
8. How do I place an order?
When we make the deal, a, you can send us a purchase order with details. b, we can send you a sales confirmation. c, we can confirm order by Aliabba too.
9. How to make the payment?
We accept Alibaba Credit Guarantee,T/T,Alipay,Paypal,Western Union and Visa.
10. Do you have samples?
Yes! For regular items, we will keep stock. You can ask for dummy samples or real samples. The samples can be shipped by your express account, or you can pay us the freight, and we will ship via our account.
11. How long we can get the goods?
It depend on the QTY.
